How to correctly plan the high-level storage of the drive-in shelf?

1. In order to better use the drive-in racks of storage rack manufacturers, it is necessary to pay attention to the review and study of the system characteristics applied in the warehouse when designing a new warehouse or transforming an existing warehouse, for example If you want to achieve the maximum storage capacity in the smallest space of the drive-in rack, you need to choose a reasonable and economical logistics plan.

2. When using drive-in racks, loading and unloading needs to be carried out from one side. This mode of loading and unloading goods can effectively improve time efficiency and work efficiency.

3. The drive-in rack of the storage rack manufacturer is a continuous shelf that is not divided by aisles, so it needs to be stored on the support rail (corbel beam), and the tray is stored in the depth direction, and it needs to be stored tightly. This can make high-density storage possible.

4. Drive-in racks can be divided into one-way and two-way arrangements according to the pick-up direction. The total depth of the one-way (wall area) shelf is preferably controlled within the depth of 6 pallets, and the two-way (the middle area can be picked up on both sides) shelf area The total depth is best controlled within 12 pallets to improve the efficiency and reliability of forklift access.

5. The drive-in rack design of the storage rack manufacturer should not be too high. It usually needs to be controlled within 10M. In order to enhance the stability of the entire rack system, in addition to larger specifications and selections, a tensioning device must be added. .

6. When using the drive-in rack of the storage rack manufacturer, the single pallet should not be too large or too heavy, and the weight can generally be controlled within 1500KG, and the pallet span should not be greater than 1.5M; often the forklift is forward-moving Battery forklift or counterbalance battery forklift.

7. Drive-in racks require very high stability due to the denser storage of goods. Relatively many rack accessories are required for this. Generally speaking, accessories are connected to the rack pillars to ensure that the goods can be safely and densely connected. Store on the corbel beam to make greater use of space.
